Default Nova 63 ls swap

We started on a LS swap on a 1963 Nova
This little ride had a 283 with a Muncie 4 speed. The 62-63 cars only had a 194 cubic inch 6 cylinder in them from the factory. This one was a three speed on the column.
The donor is a 2014 Camaro 426 hp 6.2 LS with a Tremec TR6060 manual 6 speed.
The engine and tranny are a complete pull out from this car.
We took the front end off the Nova and installed a complete aftermarket stub with Mustang ll suspension, power rack, 2" drop spindles and drilled and slotted rotors.
First thing we had to do was, cut out the tranny tunnel because the Tremec is so much bigger than the Muncie 4 speed that was in the car.










Attached Images
File Type: jpeg 1.jpeg (89.9 KB, 49 views)
File Type: jpeg 2.jpeg (87.2 KB, 50 views)
File Type: jpeg 3.jpeg (77.7 KB, 50 views)
File Type: jpeg 4.jpeg (84.0 KB, 48 views)
File Type: jpeg 5.jpeg (92.3 KB, 49 views)
File Type: jpeg 6.jpeg (86.8 KB, 48 views)
File Type: jpeg 7.jpeg (97.0 KB, 48 views)
File Type: jpg 8.jpg (170.1 KB, 49 views)
File Type: jpg 9.jpg (163.1 KB, 48 views)
File Type: jpg 10.jpg (168.6 KB, 51 views)
Reply With Quote
  #2
Old 09-04-2020, 09:04 AM
Torchie's Avatar
Torchie Torchie is offline
Rusty Rat Rodder

Join Date: Mar 2013
Location: Northern Michigan
Posts: 6,477
Default

😎😎😎😎😎😎
Iím in .........
Torchie
Reply With Quote
  #3
Old 09-04-2020, 09:17 AM
Tripper's Avatar
Tripper Tripper is offline
Older and more rusted every day!

Join Date: May 2007
Location: Central Tejas
Posts: 12,955
Default

Iron,
I put a MII clip on my '62 Nova with a power rack. It was too much & I had to remove the power assist... it was too twitchy. It would change lanes if you as much as sneezed! There are units that are adjustable... my wasn't! It stills handles just fine without assist but that's just my experience. And the MII clip made it handle like a slot car!

I'll definitely be following!!!

BoB
Attached Images
File Type: jpg menova.jpg (148.0 KB, 16 views)
__________________
Rust... Mother Nature's paint job... don't fool with Mother Nature!

RRR on Facebook
RRR on Twitter
Wanted: Ratty '35 Olds coupe!
Reply With Quote
  #4
Old 09-04-2020, 09:19 AM
Dr Crankenstein's Avatar
Dr Crankenstein Dr Crankenstein is offline
Rocket Surgeon

Join Date: Mar 2011
Location: SK CAN
Posts: 7,486
Default

Great car, great project! (I'll take the 283/Muncie if you're throwing them out.)

.
__________________
- The distinction between psychological illness and creative thinking is wafer thin -

1937 Chevy Coupe
1938 Chevy Sedan

Photo Posting and Resizing
Reply With Quote
  #5
Old 09-04-2020, 09:25 AM
Tripper's Avatar
Tripper Tripper is offline
Older and more rusted every day!

Join Date: May 2007
Location: Central Tejas
Posts: 12,955
Default

Quote:
Originally Posted by Dr Crankenstein View Post
Great car, great project! (I'll take the 283/Muncie if you're throwing them out.)
What he said!!!
__________________
Rust... Mother Nature's paint job... don't fool with Mother Nature!

RRR on Facebook
RRR on Twitter
Wanted: Ratty '35 Olds coupe!
Reply With Quote
  #6
Old 09-04-2020, 09:37 AM
forbigpicture's Avatar
forbigpicture forbigpicture is offline
Please stand by.......

Join Date: Mar 2014
Location: West by God Virginia
Posts: 5,794
Default

Sweet little ride gonna be even sweeter !!!!





__________________
Learned a lot from my mistakes....think I'll make a few more....
Reply With Quote
  #7
Old 09-04-2020, 10:37 AM
lowbudget50's Avatar
lowbudget50 lowbudget50 is offline
Creators of all things awesome

Join Date: Sep 2012
Posts: 3,659
Default

Quote:
Originally Posted by Tripper View Post
Iron,
I put a MII clip on my '62 Nova with a power rack. It was too much & I had to remove the power assist... it was too twitchy. It would change lanes if you as much as sneezed! There are units that are adjustable... my wasn't! It stills handles just fine without assist but that's just my experience. And the MII clip made it handle like a slot car!

I'll definitely be following!!!

BoB
my 50 Chevy has a bit of a touchy steering feel with the power rack also. I just got use to it.

also be watching!
__________________
Trailer queens suck! Build it, drive it and be safe!

Minterfab.com
Reply With Quote
  #8
Old 09-04-2020, 11:11 AM
Bamamav's Avatar
Bamamav Bamamav is offline
Rusty Rat Rodder

Join Date: Mar 2012
Location: Berry, Alabama
Posts: 5,119
Default

They sell a reducer that goes in the pressure port of the ps pump to make it less sensitive. The problem lies in the fact that most pumps put out more pressure than the rack needs. I know Speedway sells it, others probably do, too.
__________________
2019 Undead Sleds Calendars available here--
https://www.zazzle.com/2019_undead_s...18503957825055
Reply With Quote
  #9
Old 09-04-2020, 01:19 PM
Old Iron's Avatar
Old Iron Old Iron is offline
Rusty Rat Rodder

Join Date: May 2011
Location: Willard Mo.
Posts: 12,665
Default

I know what you're saying about twitchy.
This rack is set up for a GM pump. Yours may have been also Tripper.
If it acts up I'll add a lot of caster and if it still acts up I'll change it out for him.
Reply With Quote
  #10
Old 09-04-2020, 03:11 PM
Torchie's Avatar
Torchie Torchie is offline
Rusty Rat Rodder

Join Date: Mar 2013
Location: Northern Michigan
Posts: 6,477
Default

I'd have left it the way it was. But thats just me.
I'm sure its going to be a little beast.

Torchie
Reply With Quote
